1. Dual hydraulic chain-drive cylinders manufactured on high standard, lifting smoothly.
2. Standard door protection rubber pads to prevent possible damage to the door opened without caution.
3. Power pack with UP button and manual lowering valve handle.
4. It has been proofed by dynamic test with 115% of rated capacity and static test with 150% of rated capacity.
5. Manual two side lock release system.
6. The arm locks engage automatically when the lift is raised and disengage when fully lowered.
7. Shot blasting and high temperature baking powder coated surface finish.
| Place of Origin | Shandong, China |
| Design | Two Post |
| Type | Double Cylinder Hydraulic Lift |
| Lifting Capacity | 4000-5000kgs |
| Model Number | QD-4000CM |
| Warranty | 12 Months |
| Lifting Height | 120--1850mm |
| Overall Height | 3670mm |
| Motor power | 2.2kw |
| Power Supply | 110v/220v/380v/400v |
| Color | Red, Blue, Customizable |
| Lifing Time | 50s |
| Warranty | 3-year structure,1-year Hydraulic |
